This design guide provides a recommended design model for beams or rafters welded to an end plate which is in turn bolted to a column.
It uses the same design model as Design Guide 10 for the design of the end plate and a similar assessment procedure as Design Guide 11 for the assessment of the need for column stiffening and procedures for the design of column stiffeners.
It contains detailing and fabrication guidance, a worked example and nine design capacity tables suitable for beams or rafters inclined at between eighty and one hundred degrees to the column.
View table of contents
This title can be purchased as a hardcopy, ebook, or as a bundle of both.
